H-RAIL ON FLOOR
HORIZONTAL RAIL SYSTEM
The reduced height of the rail system on the roof provides a minimal visual impact.
The system can be used for different applications by selecting different sliding devices.
Assembly requires a limited number of fastening points with support spacing up to 6 m.
Documents
-
Technical data sheets
-
Declaration of conformity
-
Safety regulations, instructions for installation and use
-
Declaration of Installation and inspection
-
Manual for installation and use
RAIL
| CODE | description | pcs. |
|---|---|---|
| RAIL3000 | 3m aluminium rail | 1 |
| RAILC90 | 90° aluminium bend for rail | 1 |
| RAILC120 | 120° aluminium bend for rail | 1 |
| RAILC135 | 135° aluminium bend for rail | 1 |
| RAILC150 | 150° aluminium bend for rail | 1 |
SUPPORT
| CODE | description | pcs. |
|---|---|---|
| RAILBRAT | support element for rail | 1 |
| RAILBRAT12 | M12 plate for RAILBRAT | 1 |
| RAILBRATW | for fixing on wood | 1 |
| RAILBRAS | for direct fixing on steel | 1 |
| RAILBRAW | for direct fixing on wood/concrete | 1 |
TERMINAL ELEMENT
| CODE | description | pcs. |
|---|---|---|
| RAILEND | rail end-stop without exit | 1 |
| RAILENDOPEN | rail end-stop with exit | 1 |
JOINT
| CODE | description | pcs. |
|---|---|---|
| RAILJUN | junction for rails and bends | 1 |
TOOL
| CODE | description | pcs. |
|---|---|---|
| RAILJUNTOOL | template for rail junction holes | 1 |
| RAILPLATE | Rail system ID plate | 1 |
FASTENING
| CODE | description | pcs. |
|---|---|---|
| RAILOCKSCREW | Lock screw | 50 |
| RAILSCREW | DIN 7991 A2-70 | 50 |
