CONSTRUCTION SEALING
COMPRESSIBLE SEALING GASKET FOR REGULAR JOINTS
Perfect for plasterboard coating and configurations that require decoupling of elements to prevent airborne noise transmission. CONSTRUCTION SEALING has been tested within the Flanksound Project by Rothoblaas: it reduces up to 3 dB when used as an in-wall seal.
APPLICATIONS
- Plasterboard coating
- Dry floors
It is an extremely practical seal that allows sealing timber-to-timber joints both on site and during prefabrication.
Documents
-
Technical data sheets
CONSTRUCTION SEALING
| CODE | B
[mm]
|
s
[mm]
|
L
[m]
|
B
[in]
|
s
[mil]
|
L
[ft]
|
pcs. |
|---|---|---|---|---|---|---|---|
| CONSTRU4625 | 46 | 3 | 25 | 1.8 | 118 | 82 | 3 |
Technical Data
| Property | Standard | Tested Values | USC Conversion |
|---|---|---|---|
| Density | - | 0,48 g/cm³ | 0.28 oz/in³ |
| Compression deformation (22h +23 °C) | EN ISO 815 | < 25 % | - |
| Compression deformation (22h +40 °C) | EN ISO 815 | < 35 % | - |
| Thermal resistance | - | -35 / 100 °C | -31 / 212 °F |
| Storage temperature (1 ) | - | 5 / 25 °C | 41 / 77 °F |
| Solvents | - | no | - |
1. Store the product in a dry, covered location.
Composition
| SUPPORT | Extruded compact EPDM |
|---|
